Camera : CMOS Low illumination 2MP HD colorful 160° fisheye camera
Angle of View : H:160°, V:82°, D:180°
Focal Length : 1.95 mm
WDR : WDR
Noise Reduction : Noise suppression and echo cancellation
Video Encoding : H.264
Frame Rate : PAL: 25 fps; NTSC: 30 fps
Video Bit Rate : 256K to 2M
Light Compensation : IR light
Day/Night Switch : Yes
Audio Encoding : PCM G.711 A G.711 U
Audio Input : Built-in omnidirectional microphone
Audio Output : Built-in loudspeaker
Audio Bit Rate : 16 Khz 16bit
Function
Communication Methods : Digital communication
Unlock Mode : Remote unlocking
Auto Snapshot : Yes
Leave Videos or Text Messages : Yes
Web Configuration : Yes
Performance
Housing Material : Aluminum
Port
RS-485 Port : 1 RS-485 half-duplex port
Alarm Output Port : 1
Power Output Port : 1-ch DC 12V output 100mA
Unlock Button : Exit button for opening the door
Door Status Detection : Detects door magnetic status
Door Lock Control : NC/COM/NO
Ethernet Port : 10/100 Mbps self-adaptive Ethernet/2-wire
Alarm
Tamper Alarm : Tamper alarm
Regular
Ingress Protection : IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended.)
Appearance Color : Silver
Housing Material : Aluminum
Power Supply Mode : DC 12V/2-Wire IP Inteface/PoE
Installation Method : Surface mount and flush mount
Accessory : Mounting box
Dimensions : 100 mm × 100 mm × 49.30 mm
Protection Grade : IK07, IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide)
Working Temperature : –20 °C to +60 °C (–4 °F to +140 °F )
