Max 32 channels IP camera inputs, each channel up to 6MP; Max 128 Mbps incoming bandwidth
Up to 4 channels video stream (analog channel) Perimeter Protection
Up to 16 channels video stream (analog channel) SMD Plus
Up to 2 channels video stream (analog channel) human face recognition
IoT & POS functionalities
System
Main Processor : Industrial-grade processor
Operating System : Embedded Linux
Operating Interface : Web; Local GUI
Perimeter Protection
Perimeter Performance AI by Recorder (Number of Channels) : Advanced Model: 2 channels, 10 IVS for each channel / General Model: 4 channels, 10 IVS for each channel
Face Detection
Face Attributes : Gender, age groups , glasses, expressions , face mask, beard
Face Detection Performance of AI by Recorder (Number of Channels) : 2 channels (up to 12 face images/s)
Face Recognition
Face Database Capacity : Up to 10 face databases with 10,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture
Face Recognition Performance of AI by Recorder (Number of Channels) : 2 channels
SMD Plus
SMD Plus by Recorder : 16 channels : Secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change
Audio and Video
Analog Camera Input : 32 BNC ports, CVI access by default, supports HDCVI/AHD/TVI/CVBS auto-detect
IP Camera Input : Up to 32 channels of IPC access : 32 channels (analog channels are converted to IP channels) : incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
Encoding Capacity : Main stream: All channels 5M-N@(1fps–10fps); 4M-N/1080P@(1fps–15fps); 1080N; 720P; 960H; D1; CIF@(1fps–25/30fps) / Sub stream: D1/CIF@(1fps–25/30fps)
