AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map
Supports EPTZ, and one-click arming and disarming
System
Main Processor : Industrial-grade processor
Operating System : Embedded Linux
Operating Interface : Web, Local GUI
AI
AI by Recorder : SMD Plus
AI by Camera : Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Perimeter Protection
Perimeter Performance of AI by Camera (Number of Channels) : 6 channels
Face Detection
Face Attributes : Gender; age group; glasses; expressions; face mask; beard
Face Detection Performance of AI by Camera (Number of Channels) : 6 channels
Face Recognition
Face Recognition Performance of AI by Camera (Number of Channels) : 6 channels
SMD Plus
SMD Plus by Recorder : 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera : 6 channels
Audio and Video
Access Channel : 8 channels
Network Bandwidth : AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
Alarm Output : 2 channels (1-channel 12 V 1 A output)
Disk Interface : 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
USB : 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
HDMI : 1
VGA : 1
Network Port : 1 (10/100/1000 Mbps Ethernet port, RJ-45)
General
Power Supply : 12 VDC, 4 A
Power Consumption : Total output of NVR is <10 W(without HDD)
Net Weight : 1.49 kg
Gross Weight : 2.77 kg
Product Dimensions : 375.0 mm × 282.9 mm × 53.0 mm (W × D × H)
Packaging Dimensions : 433.0 mm × 141.0 mm × 366.0 mm (W × D × H)
Operating Temperature : –10 °C to +55 °C
Storage Temperature : –20 °C to +60 °C
Operating Humidity : 10%–93% (RH), non-condensing
Installation : Rack or desktop
Certifications : CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
