Lenkeng HDMI Extender over IP 4K60Hz 120m 1G LKV582

Order Code: 25797

Type: HDMI
Transmission: Over IP
Resolution: 4K60Hz
Distance: 120m
IR: Yes
Loop through: Yes

Stock Level: Only 3 pieces left

–

Price

€224.00

Promo Price (Online only)

€179.₀₀

This product is a 4K@60Hz HDMI extender kit consisting of a transmitter and a receiver, using ipcolor STREAM technology for high-definition, low-latency transmission. The 4K@60Hz HDMI signal can be extended up to 120m via Category 6 and above network cables, supporting one-to-one connection, one-to-many connections via gigabit switch, or switch cascades. It also supports HDMI loop out, IR passback, and RS-232 passthrough functions, and can be widely used in meetings, home entertainment, educational presentations, and other fields.

ipcolor STREAM
Low Latency
4K@60Hz
HDMI Loop-out
120M
One to Many
IR Pass-back
RS-232 Control
Micro-USB Upgrade
Lighning Protection-Surge Protection-ESD Protection

HDMI length ≤ 5m
Maximum transfer rate 18Gbps
Compatibility HDMI 2.0
HDCP 1.4/HDCP 2.2
Resolutions 3840x2160@24/30/50/60Hz, 1080p@50/60Hz, 720p@50/60Hz, 1920x1200@60Hz, 2560x1440@60Hz, 2560x1600@60Hz
Connection types One-to-one connection
One-to-many connection
Switch cascading
Transmission distance Cat6/6A/7≤120m
Transmission latency 70~180ms
IR receiving range ≤ 5m
IR frequency 20kHz~60kHz
RS-232 (GND/RXD/TXD) Default baud rate: 115200
Supported: 2400, 4800, 9600, 19200, 38400, 57600, 115200
Power Supply DC 5V/1A
Power Consumption TX ≤ 4.5W
RX ≤ 2.5W
Working temperature - 20℃~60℃
Storage temperature 30℃~70℃
Humidity 0~90%RH (no condensation）
Housing lron
Weight TX:254g, RX:242g
Color Black
Dimensions 106.0(L)*103.0(W)*20.6(H)mm
Protection ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
