Video & Audio

• Image Sensor : 1/3"+1/2.8"CMOS Sensor
• Video Resolutio : Up to: 3840 x 2160 (8.0 megapixels) at 25 frames/sec
• Lens : f=2.8mm@F=1.6，f=8mm@F=1.6
• Video Format : H.264,H.265
• Field of View : • Horizontal: 104°-38° /  Vertical: 60°-21°
• Zoom Mode : 6X hybrid zoom
• Day & Night : IR-cut filter with auto-switching
• Infrared Night Vision : Up to 15 meters (LED: 2pcs/850nm)
• Color Night Vision : Spotlights: 2pcs/6500K/450 lumens
• Audio : Two-way audio

Power

• PoE : IEEE 802.3af, 48V active
• DC Power : DC 12.0V⎓2A, <12W

Interface

• Power : DC power port
• System : Reset button
• Ethernet : One 10M/100Mbps RJ45
• Storage : Micro SD card slot (Max. 256GB)
• Audio : Built-in microphone and speaker

Pan&Tilt

• Pan &Tilt Range : Pan: 355°, Tilt: 0°~90°
• Pan Speed : 2.5°-90°/s (Speed can be set)
• Tilt Speed : 1.5°-60°/s (Speed can be set)
• Preset : 32
• Auto Tracking : Support

Software Features

• Frame Rate :  Mainstream: 2fps - 25fps /  Substream: 4fps - 20fps
• Code Rate :  Mainstream: 4096Kbps -8192Kbps /  Substream: 128Kbps -1228Kbps
• Browsers Supported : Edge, Chrome, Firefox, Safari
• OS Supported : PC: Windows, Mac OS; Smartphone: iOS, Android
• Smart Alarm : Motion detection; person detection; vehicle detection; pet detection (beta)
• Record Modes : Motion/scheduled recording (default: motion recording)
• Tracking Method : Digital Tracking; Pan/Tilt Tracking First; Digital Tracking First
• Protocols & Standards : HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
• Maximal User Access : Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams) / 20 users (1 admin account & 19 user accounts)
• Work with : Google Assistant

Working Environment

• Temperature : Operating temperature: -10°C~+55°C
• Humidity : Operating humidity: 10% ~ 90%
• Waterproof : Support

Size & Weight

• Dimension : 228*147*129mm
• Weight : 1.211kg
