Customizable video wall for simultaneous monitoring
Smooth archive search
Instant event-to-video alarm verification
Rapid and encrypted data transfer
Camera empowered by AI
Built-in motion detection
Keep sensitive info in the private zone
Passwordless authentication is key
Hassle-free installation and setup
Type
8 Mp/2.8 mm
Resolution up to 3840 × 2160 px
Frame rate up to 20 FPS
Viewing angle from 100° to 110°
Videostream
Video protocol : JetSparrow / Fast and encrypted peer-to-peer video protocol developed by Ajax Systems
Storage : NVR / Hard drive with a capacity of up to 16 TB (SATA connectivity, 3.5” size). Memory storage device not included
microSD : Up to 256 GB. Memory storage device not included
Video codec : H.265 / H.264
Dynamic range : True WDR
Communication channel
Ethernet : up to 100 Mbps
Key features
Motion detection : The camera has software to detect motion in the frame
Object detection using AI : Humans / Pets / Vehicles
Smart IR illumination : up to 15 m / Automatic adjustment of intensity in real time to avoid overexposure. This allows you to see objects that are far away or too close to the camera in low light conditions
Visual verification of Ajax alarms : The system allows you to set up a scenario when Ajax detectors activate selected cameras to start recording. The result is immediately sent to the mobile or desktop monitoring app
Microphone : With the corresponding settings, the camera records sound at the object
Audio codec : G711-ULAW / G711-ALAW / G726 / G722
Power supply
Power supply unit : 12 V⎓ ± 20%, 1 А / Up to 15 W of mains power consumption
Ethernet port : PoE Standard 802.3at
Sabotage protection
mTLS : Encrypted connection for data protection
Authentication : via Cloud / Without local access rights
Secure Boot : Protection against firmware spoofing
OTA signature verification : Secure automatic firmware update
Privacy : Access rights distribution for users in mobile apps and for monitoring operators in PRO Desktop
Enclosure
Dimensions : 113 × 60 mm
Weight : 360 g
Operating temperature range : from −30 °C to +60 °C
