Camera
- Image Sensor : 1/3" CMOS
- Max. Resolution : 2560 (H) × 1440 (V)
- Electronic Shutter Speed : Auto/Manual 1/3 s–1/100,000 s
- Illumination Distance : Up to 30 m (IR) / Up to 30 m (Warm light)
- Illuminator On/Off Control : Auto
- Illuminator Number : 2 (IR LED); 2 (Warm light)
- Max. Aperture : F1.6
- Field of View : 2.8 mm: H: 98°; V: 55°; D: 115°
Intelligence
- Human Detection : Support the classification and accurate detection of human
Video & Audio
- Video Compression : H.264B; H.264; H.264H; H.265
- Video Frame Rate : Main stream: 2560 × 1440@(1–25/30 fps);
- sub stream: 640 × 480@(1–25/30 fps)
- Resolution : 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720)
- Video Bit Rate : H.264: 32kbps ~ 4096kbps / H.265: 12kbps ~ 4096kbps
- Day/Night : Auto(ICR)/Color/B/W
- Motion Detection : OFF/ON
- Smart Illumination : Yes
- Image Rotation : 0°/180°
- Built-in MIC : Yes, built-in Mic
- Built-in Speaker : Yes
- Audio Compression : G.711a; G.711Mu; PCM; G.726
Network
- Network Port : RJ-45 (10/100 Base-T)
- Wi-Fi : IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G
Storage
- Micro SD card (support max. 256 GB) (64GB up to 4 days / 128GB up to 8 days / 256 GB up to 16 days )
Management
- Software : Smart PSS; DSS; DMSS
- Mobile Client : iOS;Android
Certifications
- CE-LVD: EN62368-1;
- CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
- CE-RED: Radio Equipment Directive 2014/53/EU
General
Power Supply : 12 VDC
Power Consumption : Basic: 2.2 W (12 VDC) / Max. (H.265+warm light intensity):6.6 W (12 VDC)
Operating Temperature : –40 °C to +60 °C
Operating Humidity : ≤95%
Protection : IP67
Casing Material : Metal + plastic
Product Dimensions : 131.0 mm × 78.4 mm × 97.2 mm (L × W × H)
Net Weight : 254.5 g
