Battery Input Data
- Battery Type : Lead-acid or Lithium-ion
- Battery Voltage Range : 43~60V
- Max. Charge Current : 300A
- Max. Discharge Current : 300A
- Charging Curve : 3 Stages/Equalisation
- External Temperature Sensor : Yes
- Charging Strategy for Li-Ion : Battery Self-Adaptation to BMS
PV String Input Data
- Max. DC Input Power : 18000W
- Max PV Input Voltage : 450V
- MPPT Range : 250V~450V
- Start-up Voltage : 150V
- PV Input Current : 26A + 26A + 26A
- Max. PV Isc : 44A + 44A + 44A
- No. of MPPT / Strings Per : MPPT 3 / 2
AC Output Data
- Max. On-Grid AC Power : 16000W
- Max. Off-Grid AC Power : 13000W
- Peak Power (off-grid) : 2 times of rated power, 10 S
- AC Output Rated Current : 65A
- Max AC Current : 70A
- Max Continuous AC Passthrough : 150A
- Bypass Current : 150A
- Frequency Range : 45Hz ~55Hz
- Voltage Range : 211V ~ 264V
- Grid Type : Single-Phase
- Current Harmonic Distortion : THD<3%(Linear load<1.5%)
Efficiency
- Max. Efficiency : 97.60%
- Euro Efficiency : 97.00%
- MPPT Efficiency : 99.90%
Protection (Integrated)
- PV Input Lightning Protection, Anti-islanding Protection, PV String Input
- Reverse Polarity Protection, Insulation Resistor Detection, Residual Current
- Monitoring Unit, Output Over Current Protection, Surge protection, DC
- Battery Current Protection
Certifications and Standards
- Grid Regulation : VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IEC61727,RD1699:2011, XP C15-712-3:2019-05
- Safety EMC / Standard IEC62109-1, IEC62109-2, EN61000-6-1, EN61000-6-3
General Data
- Operating Temperature Range : -25~55°C
- Cooling Fan Noise : <30dB
- Communication with BMS : RS485; CAN
- Weight : 34.5kg
- Size : 422W×702H×281D mm
- Protection Degree : IP65
- Installation Style : Wall-mounted
- Warranty : 5 years
