Dahua IP 4.0MP Dome Full Color 2.8mm WDR HDW2449T-S-LED-PRO

Order Code: 27315

Stock Level: Good

Price: €248.₀₀

4-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
Outputs max. 4 MP (2688 × 1520) @20 fps, and supports 2560×1440 (2560 × 1440) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in warm light, and the max. illumination distance is 50 m.
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Supports max. 256 G Micro SD card; built in Mic.
12 VDC/PoE power supply, easy for installation.
IP67 protection.
SMD Plus

Camera

Lens

Intelligence

IVS (Perimeter Protection) : Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
SMD : SMD Plus
Smart Search : Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression : H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec : Smart H.265+; Smart H.264+
Video Frame Rate : Main stream: 2688 × 1520@ (1–20 fps)/2560 × 1440@(1–25/30 fps) / Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps)
Stream Capability : 2 streams
Resolution : 4M (2688 × 1520) / 4M (2560 × 1440) / 3M (2304 × 1296) / 1080p (1920 × 1080) / 1.3M (1280 × 960) / 720p (1280 × 720) / D1 (704 × 576/704 × 480) / VGA (640 × 480) / CIF (352 × 288/352 × 240)
Bit Rate Control : CBR/VBR
Video Bit Rate : H.264: 32 kbps–6144 kbps / H.265: 12 kbps–6144 kbps
Day/Night : Color/B/W
BLC : Yes
HLC : Yes
WDR : 120 dB
White Balance : Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control : Auto; manual
Noise Reduction : 3D NR
Motion Detection : OFF/ON (4 areas, rectangular)
Region of Interest (RoI) : Yes (4 areas)
Image Rotation : 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror : Yes
Privacy Masking : 4 areas
LDC : Yes

Audio

Alarm

Alarm Event : No SD card; SD card full; SD card error; network disconnecton; IP conflict; illegal access; moton detecton; video tampering; tripwire; intrusion; SMD; voltage detecton; security excepton

Network

Network Port : RJ-45 (10/100 Base-T)
SDK and API : Yes
Network Protocol : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Interoperability : ONVIF (Profile S/Profile T); CGI; P2P; Milestone
User/Host : 6 (Total bandwidth: 36 M)
Storage : FTP; SFTP; Micro SD card (support max. 256 GB)
Browser : IE / Chrome / Firefox
Management Software : DSS; DMSS
Mobile Client : iOS; Android
Cyber Security : Configuration encryption;Trusted execution;Digest;Security logs;WSSE;Account lockout;syslog;Video encryption;802.1x;IP/MAC filtering;HTTPS;Trusted upgrade;Trusted boot;Generation and importing of X.509 certification

Certification

Power

Power Supply : 12 VDC/PoE
Power Consumption : Basic: 2.0 W (12 VDC); 2.5 W (PoE) / Max. (H.265 + intelligence on + WDR + warm light+ illuminator intensity): 5.3 W (12 VDC); 6.4 W (PoE)

Environment
