Compatibility : Hub BP Jeweller
Key features
- Communication channels : 2G/3G/LTE / Jeweller / Wings
Operating frequencies
- 698–960 MHz
- 1,710–2,690 MHz
Connector : SMA
Sabotage protection
- External antenna breakage detection : An Ajax system is able to detect a breakage of an external antenna and notify users and the monitoring company.
Installation
- The antenna is connected to the hub’s communication channels and goes outside through holes in the hub’s casing.
- The antenna is attached to the surface using a pre-applied double-sided adhesive tape.
- Dimensions : 115.6 × 21.7 × 5.8 mm
- Cable length : 3,000 mm
- Weight : 41 g
- Operating temperature range : from –40 °C to +85 °C
- Operating humidity : up to 95%
